High-Precision Wireless Capacitive Displacement Sensor
Ultra-sensitive, non-contact position sensing with secure wireless integration for advanced precision automation systems.
Capacitive Displacement Sensor Systems
Our high-accuracy capacitive displacement sensor system is designed for advanced testing and automation platforms, delivering sub-micron detection of position, thickness, or gap variations. Data is transmitted wirelessly, enabling real-time monitoring and control. Ideal for cleanroom environments, metrology, and motion control systems, these non-contact sensors integrate seamlessly with edge and cloud architectures, supporting efficient and scalable workflows. Tilt Deflection Angle, a trusted B2B provider across North America, combines robust engineering, rigorous quality standards, and expert support to help clients implement reliable, scalable sensing solutions. Headquartered in Vancouver, BC, we leverage ongoing R&D and field-proven technologies to empower manufacturers, laboratories, and system integrators.
Core Components of Capacitive Displacement Sensor
In addition to offering products and systems developed by our team and trusted partners for Capacitive Displacement Sensor with wireless integration, we are proud to carry top-tier technologies from Global Advanced Operations Tek Inc. (GAO Tek Inc.) and Global Advanced Operations RFID Inc. (GAO RFID Inc.). These reliable, high-quality products and systems enhance our ability to deliver comprehensive technologies, integrations, and services you can trust. Where relevant, we have provided direct links to select products and systems from GAO Tek Inc. and GAO RFID Inc.
Hardware
- Active Sensing Electrode and Reference Plate – Proximity & Presence Sensors detect alignment correctness in pressure-sensitive insurance field tests.
- Capacitive Measurement IC – Chemical and Gas Sensors assist in detecting electrochemical property changes in insured asset coatings.
- Onboard Microcontroller for Signal Processing – IoT Security safeguards real-time measurements from tampering or spoofing during insurance inspections.
- Wireless Communication Module – NFC & HF RFID Readers, Tags & Accessories offer short-range diagnostics and quick calibration syncing during mobile policy assessments.
- Shielded Cleanroom-Compatible Enclosure – Biometric Devices help maintain sterile measurement conditions for lab insurance validation of pharmaceutical manufacturing units.
- Precision Mounting Fixtures – LoRaWAN Gateways collect synchronized data from spatially arranged sensors in financial risk monitoring frameworks.
Software
- Firmware managing sampling rate, digital filtering, and drift compensation
- Wireless protocol stack supporting MQTT, BLE GATT, HTTP
- Calibration interface via mobile or desktop tool
Cloud Services
- Secure cloud platform for live monitoring and analytics
- API integrations with SCADA, MES, and PLC systems
- Remote firmware updates and calibration management
Key Features & Functionalities
- Non-contact, micron-level resolution sensing
- Wireless telemetry with configurable data intervals
- Real-time drift compensation and digital filtering
- Diagnostic alerts for out-of-range or device status
- Secure communications with TLS/SSL encryptions
- OTA updates eliminate physical access needs
Benefits
- Sub-micron accuracy without mechanical contact
- Flexible wireless installation reduces cabling
- Ideal for precision manufacturing and clean environments
- Real-time data improves process control and QC
- Scalable for multi-sensor systems in labs and production
Applications
- Semiconductor wafer gap monitoring
- Precision alignment in optical assembly
- Cleanroom metrology and biotechnology
setups - Motion control in research-grade robotics
Industries
- Semiconductor manufacturing
- Medical device production
- Laboratory instrumentation
- Automation and robotics
- Aerospace component assembly
Integrations & Compatibility
- Protocols: MQTT, BLE, HTTP/S
- Systems: PLC, SCADA, MES, robotics platforms
- Cloud Providers: AWS IoT, Azure IoT Hub, Google Cloud IoT
- 3rd-party hardware: Compatible with GAO Tek and GAO RFID platform
Relevant U.S. & Canadian Industry Standards
- ASTM E2307
- ISO 9001
- CSA C22.2
Case Studies
U.S. Case Study : Semiconductor Wafer Thickness Control
U.S. Case Study : Optical Lens Alignment
A midwestern optics manufacturer deployed wireless capacitive displacement sensors during lens assembly. Precision tracking enabled sub‑micron position control, boosting yield by 18%.
Canadian Case Study: Medical Injector Calibration
A Toronto-based medical device company integrated wireless capacitive sensors in injector calibration rigs. Remote data logging ensured CSA-compliant measurement accuracy and cut setup validation time by 50%.
